The Revolution MX is our newest and most capable Revolution ever!  The MX is all about blending lightweight e-bike performance with moto like power, something never done before!

No expenses were spared to create this one of a kind, top of the line performance king! Exotic building materials such as 6061 aluminum, 7075 aluminum, carbon fiber are all beautifully manufactured and machined to our exact specifications and then welded right here in California.

At the center of the Revolution MX is the CYC Pro Gen 4 motor system, capable of pushing 6000W. With our custom 5 speed transmission, you'll be able to have both insane climbing prowess and high stop speeds, in one package.

The incredible amount of acceleration and speed meant sourcing the some of the best performing brakes we can find; the Magura MT5 quad piston performance brakes, mated to the 203mm MDR-C rotors.  This bike stops better than anything we have ever tested! To safely operate this performance bike, we have taken considerable time to dial in the suspension, needless to say, it is like floating on a cloud!

The Revolution MX offers up massive power with 6,000W and 72V battery system It can reach speeds of 50+ mph!

We have paired the Revolution MX with a completely custom drivetrain, capable of reliably handling all this power. A custom rear hub, custom 5 speed cassette, a high performance chain for high power, and custom derailleur system with integrated clutch make this perform as well as it look!

Unlike other bikes on the market in this category, the Revolution MX has 5 speeds, giving the motor extra torque and extra speed. You'll always find the right gear for the trail!

*Off road mode must be enabled on private property, Bike will ship fully compliant with Class 2 laws (750W/20 mph)

Technical Specifications

E-Bike

Motor

CYC Pro Gen 4, 6000W

Battery

USA Made, 72V (40 mile, 75mile, 100mile)

Display

Smart, intelligent display w/ 2 riding modes

Charger

84V 2A/4A/6A, 3 Pin XLR, 100-240V

Custom Programmed Satiator Intelligent, Digital Charger (optional)

Wiring Harness

Custom HPC wiring harness

Frameset

Frame

HPC Revolution Frame, 26" wheels, full internal cable routing, 157mm spacing, 9.5" travel,

Seat Binder

Alloy, 34.9 mm

Stem

FSA Orbit 1.5 ZS Internal Headset, sealed bearings

Suspension

Rear Shock

Rock Shox Vivid R2C, 9.5x3.0

Fork

Manitou Dorado, 27.5, 200mm Travel

Brakes

Front Brake

Magura MT5e Quad Piston, metallic pads, 203mm rotor

Rear Brake

Magura MT5e Quad Piston, metallic pads, 203mm rotor

Drivetrain

Shift Lever

SRAM GX DH , trigger, 5-speed

Rear Derailleur

Sram GX DH,5-speed, Medium Cage Derailleur

Cassette

Custom 5 speed cassette, 15-30T

Chain

KMC E11 EPT

Crankset

CYC 165mm crank arms

Chainring

Custom 36T chainring

Wheels & Tires

Rims

Alex Supra 35 / 26", hookless alloy, 35mm /30mm inner width, tubeless ready

Front Hub

HPC alloy, sealed cartridge bearings, 20x110mm thru-axle, 32h

Rear Hub

HPC alloy, sealed cartridge bearings, custom steel driver, 12x148mm thru-axle, 32h

Spokes

Phil Wood 12g rear / 14g front, cold rolled/cut in house, black

Front Tire

Kenda Nevegal Pro, 26x2.7

Rear Tire

Kenda Nevegal Pro, 26x2.7

Inner Tubes

Double thick, Presta Valve

Cockpit

Stem

SRAM Descendant, direct mount, 40mm length, 31.8mm bar bore

Handlebars

SRAM Descendant 6061 mtn bars, 35mm diameter, 800mm width.

Grips

Lekkie Pacemaker throttle/grips

Saddle

WTB Volt, Cr-mo rails

SeatPost

30.9mm, aluminum, black

Top Speed (Standard gearing, 72V):

6000W- 50 mph

Range:

Standard -40 Miles

Upgraded - 75 Miles

Long Range- 100Miles

Proudly American: Every aspect of the Revolution, from the initial development, the engineering, the welding, the heat treating, the powder coating, the assembly, and the testing are all done here in the USA. No other ebike company that we know of can claim that!

Electric Technology: The 6000W power system is not only light weight, but offers incredible torque and a torque sensing pedal assist system. 2 distinct power modes (street and race) gives you the ability to choose how you want to ride.

USA Built Battery: Proudly build in the USA battery features unmatched quality, performance, and safety

Premium suspension: Up to 9.5" of rear travel and 200mm front travel allows precise control and buttery smooth performance on the roughest terrain.

Unrivaled Stopping Power: Quad piston Magura MT5e with 203mm rotors give you maximum control and heat dissipation.

Incredible Grip: The custom Kenda Nevegal Pro 26 x 2.7" tires feature super sticky tread compound so you have traction in nearly any condition

Torque Sensing PAS: The intuitive torque sensor + cadence sensor constantly monitors rider input to deliver an unparalleled ride

No range anxiety: Capable of up to 100 miles of range with the optional 2400wh battery system

High Quality Components: No aspects of the Revolution MX are looked over and features the high quality components throughout.

Class Leading Warranty: With a 3 year limited warranty on the whole electric system + 5 years on the frame, rest assured we have your
back

120 Point Inspection: An industry-leading quality assurance inspection ensures your bike will not only be built correctly but will also perform as it should

Motor:

CYC Gen 4 Pro | 6000W+ Power

Range:

Up to 100 miles (optional  2400wh)*

Maximum
Performance:

285ft-lb Torque | 6300W Peak Power

50 MPH top speed

Suspension:

9.5" Frame Travel, Rock Shox Vivid RC" 9.5 x 3", 200mm Manitou Dorado

Load
Capacity:

350lb
(with upgraded 650lb rear spring)

Frame:

6061
Aluminum | Carbon Fiber w/ 9.5" Travel

Display:

Intelligent LCD Display w/ PAS Control

Class:

Class 1 | 2 |3 |Unlimited

Battery:

USA Made 72V| Up to 2400wh

Throttle:

Lekki Pacemaker, full twist

Weight

70lb-82.6lb, option dependent

Trailblazer Warranty:

3 Year
(limited): Motor, Controller, Throttle, Battery, Charger, Display

Frame: 10 Year (limited)

Components:
Follows original manufacture warranty

For further details, please look at the HPC Terms and Conditions
