E-Bike Headsets: Cane Creek 40 vs 110 Series and Why Stock Headsets Fail

The headset is one of the least glamorous parts on a bike, and one of the first to complain when a bike is heavy, fast, and ridden hard. At Hi Power Cycles we build high-power e-bikes, so headset choice is something we pay attention to. This post compares the two Cane Creek lines we stock, the 40 Series and the 110 Series, and explains our perspective on why entry-level stock headsets are a common weak point.

Why stock headsets tend to fail on e-bikes

A headset has one job: let the fork rotate smoothly in the frame while carrying steering and braking loads. On a heavy, high-power e-bike those loads are larger than on a typical analog bike. There is more mass to slow down, more speed to slow it from, and braking forces go straight through the fork and into the head tube.

From our perspective, the usual trouble signs on any bike are the same ones riders report on e-bikes:

• Notchy or gritty steering as bearings wear or contaminants get in.
• Play or a knock under the front brake, which means the headset has loosened or worn.
• Water and dirt getting past thin seals on wet or dusty rides.

Inexpensive stock headsets often use basic bearings and minimal sealing to hit a price. That is fine for light use, but it is where we would rather not compromise on a bike built for serious power. If you notice any of the symptoms above, inspect the headset before it damages the frame or fork interface.

Cane Creek 40 Series: the workhorse

Cane Creek describes the 40 Series as the workhorse of its headset lines. It borrows design features from the premium 110 Series and aims for a balance of performance, durability, and value. The version we stock is the Cane Creek 40-Series ZS44/28.6/H8 | ZS56/40/H12, priced at $80.

• Fits a 1-1/8" to 1.5" tapered head tube designed for ZeroStack headsets.
• Can be used with a 1-1/8" steerer tube by adding the Cane Creek Conversion Crown Race, which is sold separately.
• Listed as fitting the Revolution and Revolution-M.

The 40 Series is also the headset fitted as standard on the Titan, our USA-designed, engineered, and hand-welded hardtail fat frame. The Titan product page lists a Cane Creek 40 series sealed ball bearing headset alongside the RST Renegade 120mm fork and SRAM GXe drivetrain.

Cane Creek 110 Series: the premium option

The 110 Series is Cane Creek's premium line. Per the product information we carry, it is built around Hellbender stainless steel bearings, with cups machined from 7075 series aluminum, a low-friction upper bearing seal, and a double-lip crown race seal. It is backed by a 100% lifetime guarantee, and was voted the number one headset to buy in the 2023 Vital MTB audience survey.

We stock it in two listings:

• Cane Creek 110-Series ZS44/28.6 | ZS56/40, Complete (BAA0825K), $173.
• Cane Creek 110 Series Headset ZS44/28.6/H8 | ZS56/40 (Zero Stack, tapered head tube), $155. Cane Creek's configuration range for the 110 Series includes complete assemblies or separate tops and bottoms. This listing shows Revolution-X (with the DVO fork upgrade) and Revolution-M Pro as fits.

The Titan Pro comes with a Cane Creek 110 series headset, listed alongside a RockShox Bluto fork, SRAM EX-1 drivetrain, and Maxxis Minion FBR/FBF 4.8" tires. Check the fit note on each listing against your frame, and contact us if you are unsure which size your bike needs.

40 Series vs 110 Series at a glance

• Price: 40 Series is $80; the 110 Series listings are $155 and $173.
• Positioning: 40 Series is the workhorse balance of value and durability; 110 Series is the premium line with stainless bearings, 7075 aluminum cups, extra seals, and a lifetime guarantee.
• Standard on HPC bikes: 40 Series on the Titan; 110 Series on the Titan Pro.

Which one makes sense depends on how you ride. For steady trail and backcountry riding, the 40 Series is a sound step up from a generic stock part. If you ride hard, ride in wet or dusty conditions, or want to install it once and stop thinking about it, the 110 Series is the one we would look at.

A note on White Industries

Some HPC builds go further still. The Revolution W, our limited-edition Wayne Enterprises collaboration, lists a White Industries ZS44/ZS56 headset made in the USA in its component spec. It is a good example of how far we take component choices when a bike is built without compromise.

Installation and maintenance tips

• Have the cups pressed in with the correct headset press and check that the head tube faces are properly prepared. A poorly seated cup wears out any headset.
• Set preload so there is no play, without binding the steering.
• Recheck play after your first few rides and periodically after that, especially if you brake hard or ride in the wet.
• Replace a headset that feels notchy or gritty rather than riding it until it wears the frame or fork.

Component fitment matters more than the spec sheet, so confirm your head tube and steerer standard before ordering, and check your local regulations for anything related to how and where you ride.

Shop HPC headsets and components

Ready to upgrade? Start with the Cane Creek 40 Series or the Cane Creek 110 Series, or see the bikes that use them in our electric bikes collection. Shop HPC headsets and components and reach out if you need help matching a headset to your frame.
